YOUR CONFOCAL JOURNEY STARTS HERE

A flexible, compact but full-fledged spinning-disk confocal solution, CICERO makes high-end fluorescence imaging accessible to every laboratory enabling a variety of applications.

Full compatibility
Compact
Accessible

Have a closer look at CICERO’s story!

Description

CICERO is a complete widefield and spinning disk solution, it can be integrated into any imaging setup transforming it into a user-friendly and reliable confocal system. Life sciences, metrology, and material sciences are among the disciplines relying increasingly on high-resolution 3D imaging.

Cleared mouse brain tissue section. 3D volume movie of a 120 microns Z stack. 60x Oil.

Cortical organoid. MIP of a large image. Dual channel and Z stack acquisition. 20x Air.

CICERO spinning disk solution delivers fast image acquisition speed (15K rpm) and sensitivity, easily enabling live cell imaging and large-scale 3D object imaging. Due to its large field of view (up to 22mm FOV), CICERO offers a minimal scanning process and can capture large samples in a single frame.

CICERO is a reliable and flexible solution compatible with both LED and Laser as illumination sources. Moreover, the wide spectral range enables a large variety of applications. For this, CICERO allows to address both entry-level and challenging applications.

Rat brain tissue section. MIP of a large and multichannel acquisition. 20x Dry.

Visit our Publications page to explore a collection of scientific articles, where our cutting-edge microscopy instruments have been utilized, enabling significant discoveries across various research fields

Experience the versatility of CICERO

Flexible configurations

Image Gallery

Technical Features

FOV Up to 22mm
Bypass Mode Yes (manual)
Light Source LED (3mm LLG) and multimode Laser (SMA fiber)
Spectral range Excitation: 390-750 nm ; Emission: 430-850 nm (*)
Camera C-mount camera
Resolution Lateral Resolution (FWHM): ~230 nm (100X NA 1.45) Axial Resolution (FWHM): ~600 nm (100X NA 1.45)
Software NIS Elements/μManager/ VisiView®/Volocity/ SDK available for integration
Configurations Upright and Inverted Microscope
Weight 7.65Kg | 16.8 lbs
Dimensions 166.20 (w) x 234 (l) x 228.60 (h) mm 6.54 (w) x 9.21 (l) x 9 (h) inches

* The full range is guaranteed only with light sources coupled via SMA fiber

The product packaging has been certified by the International Safe Transit Association (ISTA).

Compatibility

List of compatible products

Detectors

PCO
Teledyne Photometrics
Hamamatsu

Microscopes

Nikon
Evident (former Olympus)
Leica
Zeiss
Cairn

Illuminators

Excelitas
CoolLED
Lumencor
89-North

Software

NIS-Elements
MicroManager
VisiView
Volocity
